TPX Mode
Automated plate handling system that mechanically secures the plate to the rail during wood tie exchange
Tie Only Mode
Allows machine operation with plate handling system stored for increased versatility with wood ties near switches, crossings, and certain operating conditions
Adjustable gripper force
The gripper force for the tie gripper assembly can be adjusted for the following:
-
Tie degradation (to prevent further tie disintegration during removal)
-
Tie insertion (to prevent damage to new ties)
Operates from either side of track
82-inch-stroke-length workheads allow the operator to perform removal/insertions from either side of the track, allowing greater control in obstructed or constricted areas; the operator can also access the cab from either side of the machine.
Adjusts for different rail types and heights
Simple switch settings allow the operator to quickly adjust for jointed or welded rail. In addition, operator-controlled settings allow rail lift height adjustments for different rail heights - even different heights on left and right rails.
Stock fewer maintenance parts
TPX uses many of the same components as other Nordco machines, you can stock fewer maintenance parts in your trailers
|
Category
|
Specification
|
Value
|
|
General
|
Weight
|
44,500 lbs
|
|
|
Length
|
37’-0” (without Bumper Extensions)
|
|
|
Width
|
9’-11”
|
|
|
Working clearance
|
12’-1” (from center of track with one tie exchanger extended)
|
|
|
Height
|
11’-0”
|
|
|
Wheel base
|
27’-3”
|
|
|
Travel speed
|
21 mph (maximum)
|
|
Capacities
|
Fuel tank
|
145 gallons
|
|
|
Hydraulic tank (single)
|
185 gallons
|
|
|
DEF tank
|
10 gallons
|
|
Engine
|
Make/Model
|
Cummins Tier IV Final - QSB6.7 (225hp)
|
|
Hydraulic System
|
Pumps
|
Oil Gear PVG
|
|
|
Control valves
|
Piston pump
|
|
Electrical System
|
Battery
|
24 Vdc (dual 12V DC batteries), 1150 cold-cranking amps
|
|
Axle Drive System
|
Drive type
|
Dual-axle, chain-drive, hydraulic
|
|
Suspension
|
Spring & Shock Damper type
|
Hydraulic suspension lockout in Work Mode
|
|
Brakes
|
Type/Style
|
Hydraulically-applied, four-wheel, Cobra-style
|
|
Category
|
Option Type
|
Description
|
|
Cabin
|
Cabin accessories
|
Cab window shades, vandal guards (protective screens over cab windows)
|
|
Tie Control
|
Tie-related accessories
|
Rail lift spotting feature, tie insertion stop device, upgrades to make machine suitable for work in third-rail territory
|
|
Hydraulics
|
Pump Upgrade
|
Danfoss Series 45 (S45)
|
|
Repair & Maintenance
|
Lubrication system
|
Air-powered grease lubrication system (35# pail & 32’ hose)
|
|
|
Electric hydraulic tank fill system
|
Allows quick filling of hydraulic tank
|
|
|
Spare hose tree
|
Stores extra hoses on the machine
|
|
|
Remote coolant filter loops
|
Allows quick filter maintenance
|
|
|
Schroeder KF 30 case drain return filtration
|
Filters oil to remove engine wear-related metal filings
|
|
Other Accessories
|
Gauges and alarms
|
Fuel level site gauge, hydraulic reservoir temperature gauge, low hydraulic oil level/high hydraulic oil temperature alarm
|
|
|
Lighting and mirrors
|
Heated outside mirrors, perimeter lighting package
|
|
|
Storage
|
Additional book storage box, track tool box
|
|
|
Miscellaneous
|
“Danger Live Track” retractable belt, DOT reflective tape, extra parts/operations/maintenance manuals, rail sweeps, tow bar with D-handle hitch pins, windshield washer fluid tank and nozzles
|
