Adzer (Ride-On)

Key Features

  • Rotary, belt-driven, 20” cutterheads, with six carbide cutter bits; one extra cutter head and 50 extra Adzer bits shipped with machine
  • Deutz four-cylinder, air-cooled diesel engine; Hatz engine available Hydraulically driven dual crawlers
  • Cyclonic separator-type dust/debris collection system
  • Optional depth gauge available to automatically control continuous cutting heights
  • Ramp mechanism to adjust machine height for transversing crossings
  • Overview
  • Specifications
  • Options
  • Photos
  • Videos
  • Resources
  • Manuals

Precisely control cutter heads

Use the lever-style operator controls to precisely position the cutter heads at the desired cutting height. Or, an optional depth gauge is available to automatically control the cutting height - ensuring the same cutting height on all ties.

Quickly adjust for different rail heights

Simply adjust the pivot blocks on the Ride-On Adzer truck frame to set the machine for your current rail height conditions.

Minimize dust and debris in working area

The cyclonic-separation dust collection system collects dust and debris from the cutting head area and deposits the particles on the field side of the machine - keeping your work area cleaner and easier to view.

Easily handle crossings and obstructions

Crossings? Slide the included ramp into place to ride easily over crossings. Obstructions? Just pivot the cutting heads to move around any obstacle.


Category Specification Value
General Weight 5700 lbs
  Length Blower in travel position: 14’ 2”; blower in work position: 12’ 6”
  Width Blower in travel position: 10’ 6”; blower in work position: 13’
  Height With Deutz engine: 8’; with Hatz engine: 8’ 5”
  Wheel base 61.5”
  Travel speed 25 mph (maximum)
Capacities Fuel tank 36.8 gallons
  Hydraulic tank 36 gallons
Engine Make/Model Deutz F4L1011
  Type Four-cylinder, air-cooled diesel
Hydraulic System Make/Model Parker PAVC65
  Type Piston pump
Electrical System Battery 24 Vdc, circuit-breaker protected, 1150 cold-cranking amps
Axle Drive System Drive type Hydraulically-driven dual crawlers/chain
  Propulsion type Hydraulic
Wheels Type Pressed-steel flanged and crawler driven
  Size 14” diameter
Plates Plate storage 35 plates on deck



Category Option Type Description
Cutter Mechanism Depth gauge To ensure same cutting level height across all ties
Other Accessories Lighting and horns Travel/work lighting package, air horns



To view our parts manuals by machine type and serial number, please visit our parts manual library.
